Xynova PRM10-20-64-75-F Linear Actuator

Xynova PRM10-20-64-75-F Linear Actuator

Xynova PRM10-20-64-75-F Linear Actuator is a Xynova linear actuator for humanoid robotics, manipulation systems, research platforms, and custom robotic integration projects.

Manufacturer source: https://www.xynova.com.cn/en/linear-actuator.

Key specifications

• Micro Cylinder PRM10 Series
• effective stroke 19+1% mm
• size 10*13.5*81 mm
• no-load max speed ≥64 mm/s
• max thrust ≥75 N
• full-load speed ≥25 mm/s
• weight ≤34 g
• operating voltage DC12±10% V
• repeatability ±0.04 mm
• operating temperature -15~60°C
• static current 0.05A.

Applications

Typical applications include humanoid robot development, robotic manipulation research, industrial automation prototypes, laboratory systems, education platforms, and advanced mechatronics integration.
